R161972500 BOSCH REXROTH LUBRICATING UNIT 30 Front lube unit (KSF)

R161972500 BOSCH REXROTH LUBRICATING UNIT 30 Front lube unit (KSF), For a travel distance of up to 25,000 km without re-lubrication, Ball runner block only requires initial lubrication with grease.

Feature of R161972500 BOSCH REXROTH LUBRICATING UNIT 30 Front lube unit (KSF)

Front lube unit for ball rail systems

Size 30

For a travel distance of up to 25,000 km without re-lubrication

Ball runner block only requires initial lubrication with grease

Front lube units on both sides of the ball runner block

Low lubricant loss

Reduced oil consumption

No lubrication lines

Front lube unit can be refilled using the lube nipple on the end-face or at the side.

Lube connection on the end-face of the front lube unit is suitable for lubricating the ball runner block with grease.

Specification of R161972500 BOSCH REXROTH LUBRICATING UNIT 30 Front lube unit (KSF)

Accessories for: Runner block

Nominal size [mm]: 30

Tightening torque [Nm]: 1.2

Height runner block with guide rail [mm]: 42.0

Possible travel distance s with front lube units: 25000

Dimension A4 (profiled rail system) [mm]: 58.8

Dimension B4 [mm]: 14.5

Dimension E8 (profiled rail systems) [mm]: 48.4

Dimension E9 (profiled rail systems) [mm]: 14.6

Dimension H [mm]: 42.0

Dimension H3 [mm]: 35.05

Dimension K2 (profiled rail systems) [mm]: 6

Dimension K3 (profiled rail systems) [mm]: 6.05

Dimension K4 (profiled rail systems) [mm]: 6.05
